Gateways

RF Gateway

  • Zigbee
  • PoE
  • Indoor

Multi-band RF gateway supporting Zigbee, Z-Wave, and 433/868/915 MHz sub-GHz protocols for aggregating legacy wireless sensors into IP networks.

Specifications

RF Bands433 MHz, 868 MHz, 915 MHz, 2.4 GHz
ProtocolsZigbee 3.0, Z-Wave Plus, Sub-GHz
BackhaulEthernet + Wi-Fi
Concurrent NodesUp to 500
Power12VDC or PoE
Operating Temp-20°C to +55°C
ProtectionIP20
CertificationsCE, FCC

Specifications may vary by model and region. Final selection is confirmed during solution design.

Applications

Where the RF Gateway is used

Gateways are the backbone of the network. Getting their number, placement, antennas and backhaul right decides whether every sensor reports reliably for years.

  • Private LoRaWAN networks for buildings, campuses and master communities
  • Indoor coverage for basements, risers and plant rooms
  • Outdoor coverage for streetlights, waste bins and utility networks
  • Bridging Zigbee, RF or field-bus devices to IP and MQTT

How it connects

The RF Gateway connects over Zigbee and is integrated into your platform or BMS through a gateway that forwards its data over IP.

Protocol conversion & integration →

Installation notes for UAE projects

  • Gateway count is set by an RF survey, not by vendor range claims; dense concrete and steel cut range sharply.
  • Backhaul over Ethernet or 4G is chosen per site, with PoE where possible.
  • Gateways connect to a network server such as ChirpStack, hosted on-premise or in the cloud.
  • In the UAE, gateways are configured for the EU868 plan, subject to type approval.

FAQ

Gateways — questions

How many gateways does a building need?

It depends on construction, floor count and where devices sit. One gateway may cover several floors of an open building, while a tower with deep basements may need more. An RF survey gives the real answer.

Can we run our own private LoRaWAN network?

Yes. With your own gateways and a network server such as ChirpStack, you own the network and its data, with no per-device subscription fees.

Selecting devices for a project?

Tell us about your site, assets and existing systems. A LoRaWAN specialist will review your requirements and propose a practical architecture — no obligation.
